全部產品介紹

  1. 產品介紹
one two four
  • VIEW MORE
    FUSION200-X注射式幫浦

    11-RACK 4-RACK FOR FUSION

    注射泵浦 型號Fusion 200-X 是兩管式幫浦具有智慧型觸控玻璃螢幕, 另有提供加購模組化4注射器擴充架和模組化11注射器擴充架 11-Syringe infuse/withdraw holding rack 來增加智慧型的擴充使用.
  • VIEW MORE
    FUSION6000-X注射式幫浦--001

    FUSION6000-X高壓注射式泵浦

    FUSION6000高壓型注射泵浦
    The Fusion 6000-X high-pressure syringe pump is designed for dosing viscous solutions, and semi-solid material injections against
    pressure. This system allows also for heated temperature control and pressure modulation while providing precision flow and
    performance. It includes prime buttons that allow you to easily adjust the push blocker to the syringe.
  • VIEW MORE
    KDS100 注射式幫浦

    KDS100 注射式幫浦

    KDS100 注射式幫浦
    幫浦動作:注射式
    注射管數:單管
    注射針容量:10ul~60ml
  • VIEW MORE
    Legato200 _1_.jpg

    Legato200注射式幫浦

    Legato200, Legato210,Legato210p,Legato270注射幫浦
    Legato270 雙管注入與雙管抽取同時動作



    型號
    Legato200
    Legato210
    Legato210p
    Legato270


    注射筒數/容量
    2/0.5ul~140ml
    2/0.5ul~140ml
    2/0.5ul~140ml
    2+2/0.5ul~140ml


    精度
    +/-0.35%
    +/-0.35%
    +/-0.35%
    +/-0.35%


    最小流量(0.5ul syringe)
    3.12pl/min
    3.12pl/min
    3.12pl/min
    5pl/min


    最大流量(60ml syringe)
    105ml/min.
    105ml/min
    105ml/min
    220.97ml/min(140-ml syringe)




    https://www.kdscientific.com/media/manuals/KDS%20Legato%20100%20Series_5617-006REV2.0.pdf

  • VIEW MORE
    LEGATO110-removebg-preview _1_.png

    Legato110注射式幫浦

    Legato100, Legato101,Legato110, Legato111,Legato130 注射幫浦



    型號
    Legato100
    Legato101
    Legato110
    Legato111
    Legato130


    注射筒數/容量
    1/0.5ul~60ml
    2/0.5ul~10ml
    1/0.5ul~60ml
    2/0.5ul~10ml
    1/0.5ul~1000ul


    精度
    +/-0.5%
    +/-0.5%
    +/-0.5%
    +/-0.5%
    +/-0.5%


    最小流量
    0.1ul/hour
    1.28pl/min
    1.28pl/min
    1.28pl/min
    3.66pl/min


    最大流量
    426ml/hour
    25.99ml/min
    88.32ml/min
    25.99ml/min
    3.818pl/min




    https://www.kdscientific.com/media/manuals/KDS%20Legato%20100%20Series_5617-006REV2.0.pdf

  • VIEW MORE

    圓孔式面板插座ＲＳＪ＿ＲＭＪ

    圓孔式面板插座
    安裝簡單
    安裝不需使用特殊工具，您只需要在面板上用出一個圓孔，鎖緊提供的螺母即可。這對於要求將連接器附連在現有儀表的單一電路而言，是上佳選擇。稍微中斷操作，便可輕易將熱電偶接頭接入面板。提供方形或圆形型式，可根據線路設計選配安装。接觸件使用熱電偶接頭級别的合金，即使在環境温度變化時也可维持線路的高精準度。
  • VIEW MORE

    PCLM-SMP

    PCLM-SMP熱電偶護線夾 FOR K TYPE, T TYPE
    熱電偶接頭有 T , K , J,RS, PT100歐姆
  • VIEW MORE

    加熱棒 Cartridge Heater CSH Series

    CSH系列,加熱棒
    Lead Length: 150 mm L (6")
    Lead Insulation:
    CSH Series:
    Fiberglass, rated to 250°C (482°F)
  • VIEW MORE
    加熱繩 FGR系列.jpg

    加熱繩,FGR系列

    FGR系列,加熱繩
    Maximum Allowable Temperature: 482°C (900°F)
    Suitable for Use on Conductive Surface: Yes
    Resists Moisture, Vapor, Or Chemicals: No
    Standard Diameter: 5 mm (3/16 inch)
    Voltage: 120 Volt ac or dc, 240V optional
    Linear Wattage: 4 Watts/in. approx.
    Heater Length: 3, 6, 8, or 10 feet (0.9, 1.8, 2.4 or 3.0 m)
    Lead Length: 24 inches (609 mm)
    Termination: Stripped leads
  • VIEW MORE
    矽膠加熱帶 SRT系列.jpg

    矽膠加熱帶 SRT系列,

    SRT051-020 52W 120V 1⁄2 " x 2'
    SRT051-040 104W 120V 1⁄2 " x 4'
    SRT051-060 156W 120V 1⁄2 " x 6'
    SRT051-080 209W 120V 1⁄2 " x 8'
  • VIEW MORE

    超高溫加熱帶 STH系列

    超高溫加熱帶，SST,STH SWH,系列是由OMEGA新發展出來的加熱帶,此種加熱帶質量好，耐溫高，彈性好。可根據不同需求，選擇不同尺寸型號的產品。標準加熱帶是由電阻線以Samox雙絕緣方式編織而成,,加寬加熱帶是由兩個或更多個標準加熱帶以雙層Samox材質制成。
    其產品特點：
    (1)持續溫度可達到1400°F
    (2)短期暴露溫度釋放可達1450°F
    (3)Samox絕緣
    (4)獨立插頭
  • VIEW MORE

    玻璃纖維加熱帶 FGH 系列,

    FGH051-020 105W 120V 1⁄2 " x 2'
    FGH051-040 210W 120V 1⁄2 " x 4'
    FGH051-060 310W 120V 1⁄2 " x 6'
    FGH051-080 420W 120V 1⁄2 " x 8'
    FGH051-100 520W 120V 1⁄2 " x 10'
    FGH101-020 210W 120V 1" x 2'
    FGH101-040 420W 120V 1" x 4'
    FGH101-060 620W 120V 1" x 6'
    FGH101-080 830W 120V 1" x 8'
    FGH101-100 1045W 120V 1" x 10'
